INTEGRATED DANTE™ / AES67 NETWORKED AUDIO – Simplifies installation by enabling Dante / AES67 networked audio signals to be sent directly to the amplifier. Provides flexibility of installation options available with our expansive line-up of DriveCore Install amplifiers. Includes support for Dante 4.0 firmware for integration with Dante Domain Manager.
NETWORK CONFIGURATION, MONITORING & CONTROL – Better monitoring, control and audio manipulation with the HiQnet™ protocol over standard TCP/IP network. The HiQnet Audio Architect software allows for remote configuration, monitoring, and control of all aspects of the DCi-DA Series amplifiers.
PROGRAMMABLE GENERAL PURPOSE INPUT/OUTPUT PORT – GPIO ports can be configured in many different ways, such as volume controls, recall presets, or to report errors to third-party control system.
DIGITAL SIGNAL PROCESSING – DSP capabilities include the following:
LevelMAX Limiters
Input/Output EQ
Crossover
Delay
Matrix Router
Speaker Line Monitoring
EN 54-16 Compliant for Life Safety Applications - Part 16 of the European Union’s (EU) EN 54 standard for fire detection and alarm systems has a specific requirement for voice alarms, which output messages in the form of a voice message rather than a traditional siren. This amplifier is certified as part of an EN 54-16 VACIE*, meeting the stringent requirements of a life safety system to serve the needs of hospitality, large venue and other markets.
Specifications
| Output Channels | 8 |
| Frequency Response (8Ω, 20Hz - 20kHz) | ±0.25dB |
| Total Harmonic Distortion (at full rated power, 20Hz - 20kHz) | 0.35% |
| Damping Factor (20Hz to 100Hz) | >1000 |
| Load Impedance (Stereo/Dual Mode) | 2Ω - 16Ω; 70Vrms and 100Vrms |
| Load Impedance Bridge Mono | 4Ω - 16Ω; 140Vrms and 200Vrms |
| Cooling | Continuously variable speed forced air, front to back airflow |
| Maximum Fan Noise (re dBA SPL @ 1M) | 47 |
| Required AC Mains (±10%) | 100V-240V ~ 50/60Hz |
| Power Connector | 20A IEC |
| Dimensions (W x H x D) | 483 mm x 89 mm x 432 mm 19 in x 3.5 in x 17 in |
| Weight | 13.60 kg (30 lbs) |
