Product Overview

Christie DWU635-GS Overview

The DWU635-GS WUXGA 6750 ISO Lumens Laser Projector from Christie uses a single 0.67" DLP DMD S600HB chip to produce images when combined with a compatible lens (available separately). It supports a resolution of 1920 x 1200 and an aspect ratio of 16:10. This projector has a brightness of 6750 ISO, 6000 center, and 6000 ANSI lumens. There are two HDMI, a DVI-D, and a VGA video input, as well as an HDBaseT input. An IR remote control with jack is included.

Compatible Lenses

Lens 0.75-0.95 Zoom G/GS
Lens 0.95-1.22 Zoom G/GS
Lens Zm Std G/599-GS 1.22-1.53 (lowest cost for G/555/599/630/635-GS)
Lens Zoom HP G/GS 1.22-1.52 (all G and GS)
Lens 1.52-2.89 Zoom G/GS
Lens 2.9-5.50:1 Zoom G/GS
Lens UST 0.36 (120"), Ultra short throw lens, 630/635/700/850/1075-GS

Other Features

162 MHz pixel clock

Built-in backlit keypad

Boresight adjustable lens mount

Motorized horizontal and vertical lens offset (lens sold separately)

Motorized zoom and focus adjustment (lens sold separately)

97.5W dissipation

Built-in warping, blending, and color matching

360° orientation

Portrait mode

24/7 operation

RealBlack technology produces 4,000,000:1 full on/off contrast ratio

36 dBA noise rating

Christie DWU635-GS Specs

Display System	1-Chip 0.67" DMD DLP
Native Chip Resolution	1920 x 1200 (WUXGA)
Maximum Brightness	6750 Lumens
Offset	100% ± 100% vertical 30% ± 30% horizontal
Aspect Ratio	Native: 16:10
Contrast Ratio	250:1
Dynamic Contrast Ratio	4,000,000:1
DLP Link 3D	Yes
Supported 3D Formats	Frame Packing Side by Side Top Bottom
Color Wheel	4-Segment (R/G/B/Y)
Scan	Horizontal: 15 to 91 kHz Vertical: 24 to 120 Hz

Features

Ceiling Mountable

Yes

Input/Output Connectors

Inputs/Outputs

2 x HDMI (HDMI Type-A) Audio, Video Input
1 x DVI-D Video Input
1 x VGA (DE-15/DB-15) Video Input
1 x 1/8" / 3.5 mm Mini Remote Input
1 x HDBaseT (RJ45) Audio, Control, Video
1 x VGA (DE-15/DB-15) Video Output
1 x RJ45 Control
1 x RS-232 (DE-9/DB-9) Control Input
1 x VESA 3D Sync (RCA) Control Output
1 x VESA 3D Sync (RCA) Control Input

Hardware

Wireless LAN / Wi-Fi

Yes, Built-in

General

Light Source	Laser Phosphor
Expected Lamp Life	Medium Brightness: 20,000 Hours
Fan Noise	Medium Brightness: 36 dB Low Brightness: 34 dB
AC Input Power	100 to 240 VAC, 50 / 60 Hz at 9.5 A
Power Consumption	Medium Brightness: 650 W
Operating Altitude	10,000' / 3048 m
Operating Temperature	32 to 104°F / 0 to 40°C
Operating Humidity	0 to 85%
Dimensions (W x H x D)	19.9 x 18.0 x 7.6" / 505.5 x 457.2 x 193.0 mm
Weight	34.94 lb / 15.85 kg
