Product Overview
Record from and manage up to 8 local analog cameras at resolutions up to 2MP with the AcuSense iDS-7208HQHI-M2/S TurboHD 8-Channel 6MP Analog HD DVR with 2TB HDD from Hikvision. Additionally, this DVR supports up to four IP cameras if Enhanced IP Mode is enabled and no analog cameras are used. It is equipped with two SATA ports that support HDD storage up to 20TB (2TB preinstalled). H.265+, H.264+, H.265, and H.264 video compressions keep file sizes manageable while maintaining the best quality possible. Two-way audio communication is supported.
This DVR features motion detection and perimeter protection with human/vehicle analysis. It has VGA and HDMI video outputs to connect to external monitors.
- 8 channels and 2 HDDs 1U AcuSense DVR
- False alarm reduction through human and vehicle target classification based on deep learning
- Efficient H.265 pro compression technology
- Encoding ability up to 1080p @ 15 fps
- 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
- Up to 8 network cameras can be connected
Specification
Motion Detection 2.0¹
Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog
channels, it can classify human and vehicle, and extremely reduce false alarms
caused by objects like leaves and lights;
Quick search by object or event type is supported;
Perimeter Protection¹
Human/Vehicle Analysis Up to 4-ch
Recording
Video compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution
Main stream:
When 1080p Lite mode not enabled:
For 4 MP stream access:
4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps
For 1080p stream access:
1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
When 1080p Lite mode enabled:
4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps
(N)
Sub-stream:
WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)
Video bitrate 32 Kbps to 6 Mbps
Dual stream Support
Stream type Video, Video & Audio
Audio compression G.711u
Audio bitrate 64 Kbps
Video and Audio
IP video input2
2-ch (up to 10-ch)
Enhanced IP mode on:
4-ch (up to 12-ch), each up to 4 Mbps
2-ch (up to 18-ch)
Enhanced IP mode on:
8-ch (up to 24-ch), each up to 4 Mbps
Up to 6 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input
8-ch 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI input
3K@20 fps, 4 MP@30 fps, 4 MP@25 fps, 3 MP@18 fps, 1080p@30 fps, 1080p@25
fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps
*: The 3 MP signal input is only available for channel 1/2 of iDS-7208HQHI-M2/S,
and for channel 1/2/3/4 of iDS-7216HQHI-M2/S.
AHD input
4 MP@25 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps,
720p@30 fps
HDCVI input
4 MP@25 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps,
720p@30 fps
CVBS input PAL/NTSC
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
HDMI output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video output mode HDMI/VGA simultaneous output
Audio input3
1-ch (up to 8-ch is optional), RCA (2.0
Vp-p, 1 KΩ)
1-ch (up to 16-ch is optional), RCA (2.0 Vpp, 1 KΩ)
8-ch via coaxial cable 16-ch via coaxial cable
Audio output 1-ch, RCA (Linear, 1 KΩ)
Two-way audio 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Synchronous playback 8-ch 16-ch
Network
Remote connection 64 128
Network protocol
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,
ONVIF
Network interface
1, RJ45 10/100 Mbps self-adaptive
Ethernet interface
1,RJ45 10/100/1000 Mbps self-adaptive
Ethernet interface
Wi-Fi Connectable to Wi-Fi network by Wi-Fi dongle through USB interface
Auxiliary interface
SATA 2 SATA interfaces, up to 10 TB capacity for each disk
Serial interface RS-485 (half-duplex)
USB interface
Front panel: 1 × USB 2.0;
Rear panel: 1 × USB 2.0
Front panel: 1 × USB 2.0;
Rear panel: 1 × USB 3.0
Alarm in/out3 N/A (optional to support )
General
Power supply 12 VDC, 2.5 A 12 VDC, 3.3 A
Consumption (without HDD) ≤ 30 W ≤ 40 W
Working temperature -10 °C to 55 °C (14 °F to 131 °F)
Working humidity 10% to 90%
Dimension (W × D × H) 380 × 320 × 48 mm (15.0” × 12.6” × 1.9”)
Weight (without HDD) ≤ 1.78 kg (3.9 lb.) ≤ 2 kg (4.4 lb.)
