Product Overview
The slim, lightweight PC simply plugs in to the SMART Signage, with no need for external connection cables. By transferring power and signals internally, extra computers or clutter can be avoided. There is no need to maneuver heavy desktops or laptops, letting users save time and effort whilst reducing the risk of damage or injury.
- Great convenience
- Slim and lightweight design
Specifications
General
Device Type Digital signage player
Width 12.7 in
Depth 8.8 in
Height 1.6 in
Weight 3.97 lbs
OS Provided Windows Embedded 8.1 Industry Pro 64-bit
Interfaces USB 2.0, Gigabit Ethernet, serial, USB 3.0
Key Features Digital audio player, digital photo viewer, digital video player
Display
Output Resolution 2160p
Output Resolution on External Monitor 3840 x 2160
Processor
Manufacturer AMD
Installed Qty 1
Processor Number RX425BB
Number of Cores Quad-Core
Clock Speed 2.5 GHz
RAM
Form Factor SO-DIMM 204-pin
Technology DDR3 SDRAM
Installed Size 4 GB
Digital Storage
Storage Drive Type SSD
Capacity 64 GB
Video Output
Graphics Processor AMD Radeon R6
Max Resolution DisplayPort: 3840 x 2160 p
Memory / Storage
Storage Drive Capacity 64 GB
Connectivity
Connections DisplayPort output,
Serial
2 x USB 2.0
2 x USB 3.0
LAN (Gigabit Ethernet)
Power Device
Input AC 120/230 V (50/60 Hz)
Miscellaneous
Included Accessories DisplayPort to DVI cable
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 104 °F
Humidity Range Operating 10 - 80%
