Product Overview
Samsung interactive display WAC series offers a dynamic, engaging experience designed for the classroom of the future. WAC Series is an Android 11 OS based product, providing intuitive and convenient usability to teachers. With a variety of screen mode options, including split screen mode and multi-window mode, this display enables users to easily present and read multiple windows at once. Up to nine screens can be shared simultaneously for maximum productivity in real time, ensuring every student is included and engaged.
Display
Resolution:- 3,840 x 2,160 (Landscape)
Viewing Angle (H/V) :-178:178
Response Time :- 8ms
Operation Hours :-16/7
Diagonal Size :- 65"
Panel Type:- Direct, 60Hz
Brightness (Typical) :-400cd/m2
Contrast Ratio (Dynamic) :- 1,200:1
Connectivity
Output
RGB: N/A
VIDEO: HDMI Out (Rear)
AUDIO: 1(Stereo Mini Jack)
Touch Out: Touch Out 2 (Front 1, Rear 1)
Input
RGB: 1
VIDEO: HDMI 3(Rear 2, Front 1), USB C(Front), OPS
AUDIO: 1(Stereo Mini Jack)
USB: 5 (2.0 X1, 3.0X4)
Internal Sensor Eco Sensor
Power
Power Supply:-AC100-240V 50/60Hz
Power Consumption (Standby) :-0.5
Type :- Internal
Power Consumption
Max [W/h]: 385W
Typical [W/h]: 200W
Rating [W/h]: 350W
Stand-by [W/h]: 0.5
BTU[ W/h]: 1313
Environmental Conditions
Operating Temperature:- 104 F
Operating Humidity:- 10~80%
Features
Key :- Android App Launcher
S/W
First screen: Home UI (Multi Windows supported)
Apps: Note app, Screeshare, Finder, Browser, etc
WebRTC: Yes
Screen Share: Yes
Speaker Type :- Bulit in Speaker (12W X 2CH)
Built-in WiFi :- Yes
Built-in Speakers :- Yes
System On Chip :- Yes
H/W:- Touch Overlay(IR), Front Connectivity, OPS I/F Support(w/OPS Box), Eco Sensor, WiFi/BT Module Inbox
Orientation :-Landscape
Touch
Type :-IR
# of Drawing :-40 points to touch
Touch Pen Type :-Passive Pen
Object Recognition Range :-5mm/10mm/15mm
Touch Response Tim :-≤10ms
Haze :-25%
Drawing Speed (Touch latency) :- ≤45ms
Thickness :- 3.2T
Hardness :- Tempered Glass
Internal Player
Processor :- A55 X 4
Storage :- 32GB
Operating System :- Android 11 (AOSP)
RAM :- 4GB
Dimensions
Set Dimension (WxHxD) :- 4.88 X 2.94 X 0.28 in
Package Dimensions (W x H x D) :- 5.34 X 3.29 X 0.68 in
Weight
Package Weight:- 107.36 lbs
Set Weight :- 76.72 lbs
Accessories
Included in Box :- Power Cord, Remote Controller, HDMI Cable, Touch Pen(2ea, Black), USB Cable, Warranty/QSG
Optional Stand :- N / A (3rd party company stand/mount can be supported through VESA)
Mount :- N / A (3rd party company stand/mount can be supported through VESA)
Stand :- N / A (3rd party company stand/mount can be supported through VESA)
Mount :- N / A (3rd party company stand/mount can be supported through VESA)
Mechanical Specs
VESA Mount 600 X 400
Color Space Gray
Protection Glass Yes
Stand Type Wall Mount
Media Player Option Type OPS Slot support
Rotation Landscape only
Power Cable Length 3m
Accessory :- Power Cord, Remote Controller, HDMI Cable, Touch Pen(2ea, Black), USB Cable, Warranty/QSG
Certification and Compliance
Security 802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
Display Panel
Resolution 3,840 x 2,160 (Landscape)
Contrast Ratio (Typ) 1,200:1
Brightness (Typ.) 390cd/m2 (without glass)
Connectivity / Sounds
WiFi / BT Yes (Keyboard/Mouse)
External Control Touch Input RS232C In/Out, RJ45 In/Out
