Product Overview
The Panasonic TH-55CQE2U 55″ 4K UHD 500cd/m2 LED LCD Display is an excellent cost-effective solution that provides an array of features suitable for diverse applications, including meeting rooms, classrooms, huddle spaces, and digital signage. These displays are equipped with advanced technology and designed with ease of use in mind, ensuring seamless performance and maximum functionality at an affordable price. Whether you require a dependable display for presentations, a versatile camera for video conferencing, or a powerful signage solution for advertising and information display, these displays offer a budget-friendly option that meets your requirements without sacrificing quality.
• 4 x HDMI Inputs
• USB-C input
• ATSC Tuner (CQE2 only)
• Android OS
• 500 cd/m2 brightness (86”/75” 400 cd/m2)
• Portrait mounting
• Landscape +20° tilt mounting
supported
• Wi-Fi/Bluetooth support
• HTML5 Browser
• USB 4K Media Player
• HDMI CEC control
• RS-232/LAN control
Specifications
Display
Display Size 54.63"
Panel Type IPS-Type LCD
Aspect Ratio 16:9
Display Orientation Landscape, Portrait
Native Resolution 3840 x 2160
Maximum Brightness 500 nits / cd/m2
Lighting System Direct LED
Contrast Ratio 1200:1
Dynamic Contrast Ratio 50,000:1
Response Time 8 ms (GtG)
Refresh Rate 60 Hz
Bit Depth / Color Support 10-Bit (1.07 Billion Colors)
Viewing Angle (H x V) 178 x 178°
Screen Area 47.6 x 26.8" / 1209.6 x 680.4 mm
Horizontal Frequency 15.63 to 135 kHz
Vertical Frequency 24 to 85.06 Hz
Pixels Per Inch (ppi) 81 ppi
Finish Anti-Glare / Matte
Surface
Haze Level 1%
Video
TV Tuner Yes - ATSC
Connectivity
Inputs
4x HDMI
1x Coaxial F-Type (RF Antenna)
Outputs
1x 1/8" / 3.5 mm (Analog Audio)
1x TOSLINK Optical (Digital Audio)
HDCP Support Yes, Version 2.2
Wireless Wi-Fi 5 (802.11ac) / Bluetooth 5.1
NFC No
USB I/O
1x USB-A 3.0 / 3.1/3.2 Gen 1
1x USB-A 2.0
1x USB-C 3.0 / 3.1/3.2 Gen 1
Ethernet I/O 1x RJ45 Gigabit Ethernet
Other I/O
1x 1/8" / 3.5 mm Serial (RS-232C) Control Input
1x 1/8" / 3.5 mm IR Input
Speaker
Built-In Speakers Yes, 2x 10 W
Speaker Configuration 2-Channel
Hardware
Smart TV Android
OS Compatibility Windows
Mobile App Compatible Yes: Android Only
Media Card Reader 1x microSDXC
Built-In Mic No
Supported File Formats
Supported Video File Types AVI, H.263, H.264/AVC, H.265/HEVC, MJPEG, MPEG, MPEG2, MPEG4, VC-1, VP8, VP9, WMV3, Xvid
Supported Audio File Types AAC, APE, FLAC, MP1, MP2, MP3, PCM-WAV, WMA, WMA8, WMA9
Supported Photo File Types BMP, GIF, JPEG, PNG
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 20 to 80%
Electrical
Power Consumption Typical: 148.0 W; Standby: 0.5 W
Input Power 110 to 127 VAC, 60 Hz
Power Adapter Type Internal
General
Mounting-Hole Pattern 400 x 400 mm
Lighting Lifespan 50000 Hours
IK Rating No
Bezel Thickness 11 mm (Right/Top/Left) ,13.8 mm (Bottom)
Duty Cycle 16 Hours / 7 Days
Dimensions 48.7 x 28 x 2.7" / 1236 x 710 x 68 mm
Weight 39.5 lb / 17.9 kg
Packaging Info
Package Weight 47.78 lb
Box Dimensions (LxWxH) 53.25 x 34 x 6.5"
