Product Overview
NEC's 55" UN552V sets the standard for quality color reproduction in video wall environments. Direct LED backlighting and factory calibration for intensity, gamma and RGB allows for ideal panel uniformity and an easy out-of-the-box experience. This display is integrated with the proprietary SpectraView Engine, which not only allows for ultimate color control but also allows for increased color calibration capabilities including white copy, self calibration to an external sensor and manual CIE chromaticity adjustment for maximum control when color matters most. This display also includes both a DisplayPort and an HDMI Out connections for daisy chaining signals up to 4K UHD. This new generation of display received a full chassis upgrade with faster processing times, evolved daisy chain performance, and new TileMatrixing capabilities all while maintaining the minimal 3.5mm bezel gap.
- SpectraView Engine exclusive color processing allows for an unparalleled level of color control, uniformity, accuracy and stability
- 500cd/m2 panel brightness combined with full HD resolution will capture the attention of the audience
- Industrial-strength, premium-grade panel with additional thermal protection, internal temperature sensors with self-diagnostics and fan-based technology, allow for 24/7 operation
- HDMI and DisplayPort daisy chain capabilities can support up to 4K UHD resolution
- New TileCut function added to the TileMatrix functionality for ultimate adjustment of the imagery in the wall
- Uniformity calibration of each display for gamma, intensity and RGB for consistency from display to display
- NEC Display Wall Calibrator, MultiProfiler, and NaViSet Administrator 2 software compatible.
Specifications:
Display
| Panel Technology | S-IPS | Viewable Image Size | 55 " |
| Aspect Ratio | 16:9 | Native Resolution | 1920x1080 |
| Pixel Pitch | 0.5 mm | Pixels Per Inch | 45 @ native resolution |
| Backlight Type | LED Direct-lit | Brightness (maximum) | 500 cd/m2 |
| Contrast Ratio (typical) | 1200:1 (without local dimming) | Viewing Angle (typical) | 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 |
| Response Time (Gray to Gray) | 8 ms | Refresh Rate | 60Hz |
| Active Screen Area | 47.62 x 26.79 in. / 1209.6 x 680.4mm | Orientation | Landscape/Portrait |
| Displayable Colors | More than 1.07 billion |
| |
Synchronization Range
| Horizontal (Analog/Digital) | Analog: 15.625/15.734/~31.5-~91.1 kHz, Digital: ~25.0 - ~91.1-~134.0KHz |
|
Input Signal
| Video | Analog RGB 0.7 Vp-p/75 Ohms , Digital TMDS / DisplayPort | Sync | Separate sync: TTL Level (Positive/Negative) |
Calibration
| Factory Calibration | Yes | Sensor Calibration (through USB) | Yes, External |
| Calibration with Software | NEC Display Wall Calibrator (KT-LFD-CC2) | Calibration Software | NEC Display Wall Calibrator (KT-LFD-CC2) |
Signal Compatibility/Connectivity
| PC Signal Compatibility | Yes | Macintosh Signal Compatibility | Yes |
| Video | Analog RGB 0.7 Vp-p/75 Ohms , Digital TMDS / DisplayPort | Sync | Separate sync: TTL Level (Positive/Negative) |
| Input Terminals Analog: VGA 15-pin D-sub Digital: DisplayPort 1.1/1.2 x2, HDMI 1.4/2.0 x2, DVI-D Audio: Audio Mini-Jack x2, DisplayPort Audio, HDMI Audio External Control: RS-232C, LAN (100Mb), 3.5mm Mini-Jack (IR Remote) Data: microSD (Media Player), USB 2.0 (Media Player, USB (Service), USB Type-B (Upstream), USB x 2 (Both for Compute Module, 1 x 5V/2A Powered) | Output Terminals Digital: DisplayPort (Output DisplayPort1 and OPTION (DP)), HDMI (Outputs HDMI1, DVI and OPTION (TMDS)) Audio: 3.5mm Mini-Jack, External Speaker Jack (2) External Control: LAN (100Mb) | ||
Power Consumption (typical)
| On | 110W | ECO Mode Standby | <0.5W |
| Power Consumption (max) | 165W (Brightness Max), 315W (All Functions Maxed) | Input Current | 3.6A @ 100V, 1.4A @ 240V |
Physical Specifications
| Bezel Width (Left/Right, Top/Bottom) | 0.09 in./0.05 in., 0.09 in./0.05 in. : 2.3 mm/1.2 mm, 2.3 mm/1.2 mm | Dimensions (WxHxD) Without stand: 47.8 x 27 x 4.1 in. / 1213.4 x 684.2 x 103.8 mm Shipping: 56.5 x 34.4 x 12.5 in. / 1436.0 x 873.0 x 317.0mm | |
| Weight Net Weight (with stand): 61.9 lbs. / 28.1kg Net Weight (without stand): 61.9 lbs. / 28.1 kg. Shipping: 83.8lbs. / 38.0kg | VESA Hole Configuration | 400 x 400mm (4-hole, M6) | |
Environmental Conditions
| Operating Temperature | 41-104°F / 5-40°C | Operating Humidity | 20-80% |
| Operating Altitude | 9843 ft. / 3000m | Storage Temperature | -4-140°F / -20-60°C |
| Storage Humidity | 10-90% | Storage Altitude | 40,000 ft. / 12,192m |
Limited Warranty (parts & labor)
| 3 years |
|
Additional Features
|
|
Accessories
| Optional |
|
