Product Overview
Create pixel perfect imagery with the high-end panel quality of the new fully commercial NEC MA Series large format displays with clear tempered 10-point IR touch pre-installed. By implementing premium features and focusing on creating impressionable digital signage experiences, the MA series gives customers an elite display option with its one-of-a-kind wide color gamut commercial panel coupled with the proprietary SpectraView Engine capabilities while also allowing customers the modularity possibilities to customize their product based on their needs and application. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters - the message. Robust connectivity options allow customers to have up-to-date connectivity options while also allowing for enhanced daisy chain capabilities when tying displays together for video or control signal distribution. The NEC MA series boasts 500 cd/m2 brightness which is ideal for a majority of high end digital signage applications in restaurants, command and control, retail, museums and corporate environments when high-end and feature rich displays are necessary to convey important messaging.
Specifications:
Display
Panel Technology |
U-IPS |
Viewable Image Size |
55 " |
Aspect Ratio |
16:9 |
Native Resolution |
3840x2160 |
Supported Resolutions |
DIsplayPort: V1.4 - Up to 7680 x 4320 (30Hz - compressed image)HDMI: V2.0 - Up to 4096 x 2160 (60Hz) |
Pixel Pitch |
0.32 mm |
Pixels Per Inch |
81 @ native resolution |
Backlight Type |
LED Edge-lit |
Brightness (typical) |
500 cd/m2 |
Contrast Ratio (typical) |
≥8,000:1 (Out of the box conditions, local dimming ON) |
Viewing Angle (typical) |
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 |
Response Time (Gray to Gray) |
8 ms |
Refresh Rate |
60Hz |
Active Screen Area |
47.2 x 26.8 in. / 1209.6 x 680.4mm |
Orientation |
Landscape/Portrait |
Dimming Capability |
Local Dimming Capable |
Displayable Colors |
More than 1.08 billion (10-bit) |
Color Temperature (Max) (°K) |
15000K |
Color Temperature (Min) (°K) |
3000K |
Gamma (Typical) |
Custom adjustment from 0.5 - 4.0 (0.1 increments) through SpectraView Engine, sRGB, L Star, Rec. 1886, HDR-Hybrid Log, HDR-ST2084 (PQ), DICOM, Programmable |
