Product Overview
NEC NP-U321H Overview
The NEC NP-U321H 3200-Lumen 1080p Ultra-Short Throw DLP Projector features 3200 lumens of brightness with an ultra-short throw ratio of 0.25:1. It has HDMI, VGA, and composite video inputs, plus a VGA output for loop-through. The NP-U321H includes an RGB cable and a remote control.
Key Features
- Brightness of 3200 Lumens
- Full HD 1080p Native Resolution
- Ultra-Short 0.25:1 Throw Ratio
- Two HDMI w/HDCP, Composite, VGA Video In
- VGA Output for Loop-Through
- Analog Audio Input and Output
- Integrated 8-Watt Speaker
- Includes RGB Cable and Remote Control
NEC NP-U321H Specs
Image Display
| Display System | 1-Chip 0.65" DMD DLP |
| Native Chip Resolution | 1920 x 1080 (Full HD) |
| Supported Resolutions | VGA SVGA XGA WXGA WXGA+ SXGA SXGA+ UXGA |
| Maximum Brightness | 3200 Lumens |
| Aspect Ratio | Native: 16:9 |
| DLP Link 3D | None |
| Supported 3D Formats | None |
| Scan | Horizontal: 15 to 100 kHz Vertical: 50 to 120 Hz |
Lens
| Focus | Manual |
| Lens | f/1.80 (f = 4.78 mm) |
| Optical Zoom | 1.4x |
| Throw Distance | 18.7 - 22" / 47.498 - 55.88 cm |
| Throw Ratio | 0.25:1 |
| Projection Size | 85 - 100" / 215.90 - 254.00 cm |
Features
| Keystone Correction | Vertical: ± 5° |
| Ceiling Mountable | Yes |
| Rear Screen Projection | Yes |
| Built-In Speaker | Yes |
| Speaker Power | 8W |
| Closed Captioning | Yes |
Input/Output Connectors
| Internal Storage | None |
| Wireless LAN / Wi-Fi | None |
General
| Lamp Power | 260 W |
| Expected Lamp Life | Medium Brightness: 3000 Hours Low Brightness: 4000 Hours |
| Fan Noise | Medium Brightness: 34 dB Low Brightness: 29 dB |
| Security | Cable Lock Slot |
| Power Consumption | Medium Brightness: 323 W Low Brightness: 272 W Standby Mode (Lamp Off): 3 W Standby Mode (Lamp Off): 0.18 W |
| Dimensions (W x H x D) | 15.1 x 3.3 x 12.1" / 383.0 x 85.0 x 308.0 mm |
| Weight (lb) | 10.4 |
Packaging Info
| Package Weight | 19.5 lb |
| Box Dimensions (LxWxH) | 20 x 19.5 x 9.5" |
Warranty Information
1 Year Parts & Labor Manufacture Warranty
