Panasonic PT-MZ682B 6500 Lumen WUXGA Laser 3LCD Projector (Black)

Panasonic

(No reviews yet) Write a Review
$10,498.98
Panasonic PT-MZ682B 6500 Lumen WUXGA Laser 3LCD Projector (Black)
SKU:
PT-MZ682BU7
UPC:
885170430792
Shipping:
Calculated at Checkout
Adding to cart… The item has been added

Product Overview

Panasonic PT-MZ682 Specs

Display System
3-Chip 0.76" LCD
Native Resolution
1920 x 1200
Maximum Brightness
6500 Lumens (ISO)
Throw Ratio
1.61 to 2.76:1 (150" Screen Size @ 23' / 7.0 m)
Projection Size
40 to 400" / 1.0 to 10.2 m
HDR Support
Yes
Inputs/Outputs
3x HDMI Audio, Video Input
1x RJ45 (HDBaseT) Audio, Control, Data, LAN, Remote, Video Input
1x DE-15/DB-15 (VGA) Video Input
1x 1/8" / 3.5 mm Mini Audio Input
1x DE-15/DB-15 (VGA) Video Output
1x 1/8" / 3.5 mm Mini Audio Output
1x USB-A Power Output
1x 1/8" / 3.5 mm Mini Remote Input
2x DE-9/DB-9 (RS-232) Control, Remote Input
1x DE-9/DB-9 (RS-232) Control, Remote Output
1x RJ45 (Ethernet) LAN Input
Light Source
Laser Phosphor
Image Display
Display System
3-Chip 0.76" LCD
Native Resolution
1920 x 1200
Supported Resolutions
Maximum: 4096 x 2160 @ 60 Hz
Maximum Brightness
6500 Lumens (ISO)
Aspect Ratio
Native: 16:10
Supported: 16:9
Supported: 4:3
Dynamic Contrast Ratio
3,000,000:1
Lens
Includes Lens
Yes
Focus
Manual Powered
Aperture
f/1.7 to 2.3
Focal Length
26.8 to 45.5mm
Lens Shift
Vertical: ± 67%
Horizontal: ± 35%
Optical Zoom
Powered: 1.7x
Throw Distance
4.58 to 78' / 1.4 to 23.8 m
Throw Ratio
1.61 to 2.76:1 (150" Screen Size @ 23' / 7.0 m)
Projection Size
40 to 400" / 1.0 to 10.2 m
Features
Keystone Correction
Manual to Vertical: ± 25°
Manual to Horizontal: ± 30°
HDR Support
Yes
Multi-Input Support (PIP/PBP)
Not Specified by Manufacturer
Ceiling Mountable
Yes
Rear Screen Projection
Yes
Built-In Speaker
No
Projection Tilt Option
Yes
Input/Output Connectors
Inputs/Outputs
3x HDMI Audio, Video Input
1x RJ45 (HDBaseT) Audio, Control, Data, LAN, Remote, Video Input
1x DE-15/DB-15 (VGA) Video Input
1x 1/8" / 3.5 mm Mini Audio Input
1x DE-15/DB-15 (VGA) Video Output
1x 1/8" / 3.5 mm Mini Audio Output
1x USB-A Power Output
1x 1/8" / 3.5 mm Mini Remote Input
2x DE-9/DB-9 (RS-232) Control, Remote Input
1x DE-9/DB-9 (RS-232) Control, Remote Output
1x RJ45 (Ethernet) LAN Input
HDCP Support
Yes, Version 2.3
Media/Memory Card Slot
No
Hardware
Mobile App Compatible
Yes: Android & iOS
App Name: Smart Projector Control
Functionality: Adjust Settings, Setup
Wireless LAN / Wi-Fi
No
Bluetooth
No
General
Light Source
Laser Phosphor
Expected Lamp Life
Full Brightness: 20,000 Hours
Fan Noise
Full Brightness: 34 dB
Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
Full Brightness: < 360 W
Operating Conditions
32 to 113°F / 0 to 45°C at 20 to 80% Humidity
Dimensions (W x H x D)
22.0 x 8.8 x 17.3" / 560.0 x 224.0 x 439.0 mm (Including Lens and Protruding Parts, with Legs at Shortest Position)
Weight
41 lb / 18.6 kg
