Netgear GSM4328PA-100NES M4300-28G-PoE+ 26-Port 1G/10G PoE+ Compliant Managed Network Switch with SFP+ (480W)

Netgear

(No reviews yet) Write a Review
$2,870.00
SKU:
GSM4328PA-100NES
UPC:
606449112771
Shipping:
Calculated at Checkout
Adding to cart… The item has been added

Product Overview

Netgear M4300-28G Overview

Expand your small to medium-sized business's network capacity with the M4300-28G PoE+ 26-Port 1G/10G PoE+ Compliant Managed Network Switch from Netgear. This fully managed rackmount network switch includes Layer 2, 3, and 4 feature sets, such as hot-swappable mixed stacking, with up to eight switches in a single logical switch, but no license requirements to support video broadcast and other high-bandwidth applications.

With 24 PoE+ compliant Gigabit Ethernet ports and a 480W power budget, you can provide power and data to IP cameras, access points, VoIP phones, and more. This switch includes a 550W power supply with support for a second PSU for redundancy and increased PoE capacity. The M4300-28G-PoE+ also includes two 10G RJ45 ports alongside two 10G SFP+ ports for high-speed uplinks. The MM4300-28G-PoE+ is designed to smoothly transfer data with a 128 Gb/s switching capacity and 95.2 Mpps forwarding rate. Your data is secured by features such as access control, private VLANs, and denial of service (DoS) attack protection.

Reliability High Availability (HA)
Nonstop forwarding (NSF) virtual chassis architectures with hitless failover across the stack.
Multi-Resiliency
Stacking and distributed link aggregation allow for zero downtime and load balancing capabilities.
PVST+ Interoperability
Per VLAN Spanning Tree and Per VLAN Rapid Spanning Tree (PVSTP/PVRSTP).
Link Dependency
Enables or disables ports based on link state of different ports.
Advanced IPv4/IPv6 Security
Malicious code detection, DHCP Snooping, IP Source Guard protection, and DoS attacks mitigation.
Easy to Manage Simple GUI
Fully functional web console (GUI) for IT admins who prefer an intuitive graphical interface.
Flexible & Efficient
Line-rate Spine and Leaf topologies offer many possibilities for server rooms, branch collapsed cores, or at the edge of growing networks.
Mix & Match Stacking
Stack between 10/40 Gigabit and 1 Gigabit models using any 10G/40G port, with any media type (RJ45, SFP+, DAC cables). Vertical, horizontal, manage as one unit.
Room to Grow
With PoE+, plug-and-play ports, and hot-swap, you're ready to grow whenever you need to.
Ready for AV-over-IP Zero-Touch AV-over-IP
Preconfigured for out-of-box L2 multicast (SDVoE-ready).
No Delay
Non-blocking fabric for near-zero switch latency.
Netgear IGMP Plus
Prevent network flooding with multicast implementation of Layer 2 multicast.

Netgear M4300-28GSpecs

Inputs/Outputs
24x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at)
2x RJ45 10 GbE
2x SFP+ 10 GbE
1x RJ45 Gigabit Ethernet LAN
1x RJ45 RS-232 (Console)
1x Mini-USB LAN
1x USB-A
Stackable
No
Switching Bandwidth
128 Gb/s (Non-Blocking)
PoE Power Budget
480 W
Stackable
No
Protocols
Layer Services Supported
Layer 2, Layer 3, Layer 4
Supported Protocols
Auto-VoIP
DHCP Server
IGMP Snooping
IPv4
IPv6
Link Aggregation
RADIUS
MAC Address Table Size
16K
Security
Security Features
DHCP Snooping
DoS Attack Prevention
RADIUS Authentication
Storm Control
Performance
Latency
1.9 to 3.8 µs
Forwarding Rate
95.2 Mpps
Switching Bandwidth
128 Gb/s (Non-Blocking)
Packet Buffer
16 Mb
Computer
Flash Memory
256 MB
CPU
Single-Core: Up to 800 MHz
Memory
1 GB
Electrical
PoE per Port
30 W
PoE Power Budget
480 W
Power Draw
577.00 W (Max)
Input Power
110 to 220 VAC, 50 / 60 Hz
Power Supply Type
Internal
General
Certifications
No
Noise Level
39.8 dB
Cooling System
Fan
Mean Time Between Failures (MTBF)
1.3 Million Hours
Indicator Lights
Yes
Rack Mountable
Yes 1 RU
Dimensions
17.3 x 12.2 x 1.7" / 44 x 31 x 4.4 cm
Weight
11.22 lb / 5.09 kg
Packaging Info
Package Weight
14.925 lb
Box Dimensions (LxWxH)
22.8 x 17.4 x 3.8"
