- Lifelike images — high native contrast ratio, HDR support and scene adaptive gamma correction for more realistic images and easy-to-read presentations
- Optional external air filter — extend the filter maintenance cycle in dusty environments
- Dynamic projection capabilities — advanced built-in Edge Blending, image warping and shape overlay features for a variety of applications; direct content playback from USB storage media
- Customized performance — brightness modes to maximize light source life and provide a consistent brightness level
- Powerful remote management — control and monitor projector status via the Epson Projector Management app for Windows
Eco Features
- RoHS compliant
- Recyclable product10
- Epson America, Inc. is a SmartWay® Transport Partner11
Better Products for a Better Future™For more information on Epson's environmental programs, go to
eco.epson.com.
What's In The Box:
- EB-PU1008W projector
- Power cable
- Remote control with 2 batteries
- Cable cover
- Lens connector cap
- User guide
- Warranty sheet
Specifications
Projection System High-Aperture Epson 3LCD,
3-chip technology
Projection Method Front/rear/ceiling mount
Driving Method Poly-Silicon TFT Active Matrix
Pixel Number 2,304,000 dots (1920 x 1200) x 3
Signal Input Maximum Display Resolution: 4096 x 2160
pixels (resizing display); Display Resolution: 1920 x 1200 pixels
Native Resolution WUXGA with 4K Enhancement1
(1920 x 1200 x2)
Resolution on Screen WUXGA with 4K Enhancement1
/4.6
million pixels1
Aspect Ratio Supports 4:3, 16:10, 16:9*, 21:9*
* With vertical image shift control within letterbox area.
Pixel Arrangement Cross stripe
Color Brightness3 Color Light Output: 8,500 lumens
White Brightness3 White Light Output: 8,500 lumens
Contrast Ratio Up to 2,500,000:1 (Dynamic Contrast: On)
Brightness Uniformity (Typical) 85%
Color Reproduction Up to 1.07 billion colors
Keystone Correction
Vertical: ±45 degrees;
Horizontal: ±30 degrees
Illumination Technology Laser Phosphor
Projection Lens (Standard)
See website for information on optional lenses.
Standard Lens ELPLM08 (sold separately)
Type Powered shift/focus/zoom
F-Number 1.7 – 2.3
Focal Length 24.0 mm – 38.2 mm
Zoom Ratio Optical zoom 1.0 – 1.6x
Throw Ratio Range 1.45 – 2.32
Lens Shift Vertical: ±67%; Horizontal: ±30%
Other Features
Operating Temperature 32 ËšF to 113 ËšF (0 ËšC to 45 ËšC)
Power Supply Voltage 100 V – 240 V AC ±10%, 50/60 Hz
Power Consumption
559 W (Normal, Custom)
469 W (Medium, Quiet, Extended)
2.0 W Standby (Communication On)
0.5 W Standby (Communication Off)
Fan Noise 35 dB (Normal Mode), 34 dB (Medium Mode),
30 dB (Eco Mode)
Security Security cable hole, lens lock, Kensington
lock provision, wireless LAN unit lock
Video I/O
Input Signal Input Video Signal (HDMI, DVI-D and HDBaseT
ports) 480i/480p/576i/576p/720p/1080i/1080p/3840 x
2160/4096 x 2160 - Max PC graphics: 2560 x 1600
Auto Power On Signal Detection on HDMI/Plug-In Detection
(HDMI, VGA 15-pin)
Sleep Mode Yes (with timer)
HDMI CEC Control Yes
Dimensions (W x D x H)
Excluding Feet, Lens 21.5" x 17.2" x 6.5"
Weight 35.9 lb
Remote Control
Features Power, source search selection, lens shift, zoom,
focus, test pattern selection, A/V mute, freeze, user ID, auto,
aspect, color mode, number, page up and down, E-Zoom,
volume, help, menu, enter, ESC and pointer functions
Operating Angle
Angle Front: Right/Left: 60 to +60; Upper/Lower: +30
to 20 degrees
Angle Rear: Right/Left: 30 to +30; Upper/Lower:+50
to +10 degrees
Operating Distance 98 ft
Eco Features
RoHS compliant
Recyclable product10
Epson America, Inc. is a SmartWay® Transport Partner11
Support
Epson ConnectionSM
Pre-Sales Support (U.S. and Canada): 800-463-7766
Website: www.epson.com
Service Programs
The projector has a limited warranty of 3 years. Epson Road
Service program with free Next-Business-Day Replacement12,
PrivateLine® dedicated toll-free support (U.S. and Canada only)
What’s in the Box
EB-PU1008W laser projector, power cable, remote control with
2 batteries, cable cover, lens connector cap, user guide and
warranty sheet
Ordering Information
EB-PU1008W V11HA33920
ELPLAF46 V13H134A46
External Air Filter (ELPAF63) V13H134AD0
Ultra Short Throw Lens (ELPLX01S) V12H004X0A
Ultra Short Throw Lens - White (ELPLX01WS) V12H004Y0A
Short Throw #1 zoom Lens (ELPLU03S) V12H004UA3
Short Throw #2 zoom Lens (ELPLU04) V12H004U04
Wide Throw #1 zoom Lens (ELPLW05) V12H001W05
Wide Throw #2 zoom Lens (ELPLW06) V12H004W06
Wide Throw #3 zoom Lens (ELPLW08) V12H004W08
Middle Throw #1 zoom Lens (ELPLM08) V12H004M08
Middle Throw #2 zoom Lens (ELPLM15) V12H004M0F
Middle Throw #3 zoom Lens (ELPLM10) V12H004M0A
Middle Throw #4 zoom Lens (ELPLM11) V12H004M0B
Long Throw zoom Lens (ELPLL08) V12H004L08
External Camera (ELPEC01) V12HA46010
Rigging Frame ELPMB59
Wireless LAN Module (ELPAP11) V12H005A02
Projector Ceiling Mount (ELPMB67) V12HA54010
Suspension Adapter (ELPFP15) V12HA55010
