Product Overview
Epson 5510 Overview
Enjoy bright, vibrant images with the Epson PowerLite 5510 5500-Lumen XGA 3LCD Projector. Its 5500 lumens of brightness, combined with its 15,000:1 dynamic contrast ratio, will help it overcome ambient light in many situations and help retain detail in dark areas of the image without compromising overall brightness. Its 1024 x 768 native resolution will help ensure that text is clear at most viewing distances.
The PowerLite 5510 features VGA, BNC component, and two HDMI inputs to support various source types. You can output the video to another projector or display with the VGA output. Its 3.5mm audio inputs and output allow for audio transmission to provide a more immersive experience. A VGA cable is included for instant connectivity, and an IR remote is included for convenient control.
High Color and White Brightness Levels
Lens Shift
HDMI Connectivity
Split Screen
Enhanced Detail
Versatile Connectivity Options
Remote Management and Control Tools
Integration Compatibility
Optional Wireless Networking
Epson 5510 Specs
| Display System | 3-Chip Polysilicon TFT LCD |
| Native Chip Resolution | 1024 x 768 (XGA) |
| Supported Resolutions | Full HD 1080p - 1920 x 1080 |
| Maximum Brightness | 5500 Lumens |
| Uniformity | 87% |
| Aspect Ratio | Native: 4:3 Supported: 16:9 Supported: 16:10 |
| Color Depth | 10-Bit (1.07 Billion Colors) |
| Scan | Horizontal: 15 to 92 kHz Vertical: 50 to 85 Hz |
| Focus | Manual |
| Lens | f/1.5 - 2.15 (f = 21.34 - 37.99 mm) |
| Lens Shift | Horizontal: ± 38% Vertical: ± 58% |
| Optical Zoom | Manual: 2x |
| Throw Ratio | 1.27 to 2.59:1 |
| Projection Size | 30 - 300" / 76.20 - 762.00 cm |
| Keystone Correction | Horizontal: ± 30° Vertical: ± 30° |
| Ceiling Mountable | Yes |
| Rear Screen Projection | Yes |
| Built-In Speaker | Yes (Mono) |
| Speaker Power | 10W |
| Wireless LAN / Wi-Fi | None |
| Light Source | Lamp (1 x UHE) |
| Lamp Power | 300 W |
| Expected Lamp Life | Medium Brightness: 10,000 Hours Low Brightness: 5000 Hours |
| Fan Noise | Medium Brightness: 38 dB Low Brightness: 28 dB |
| Security | Cable Lock Slot |
| Power Consumption | Medium Brightness: 462 W Low Brightness: 324 W Standby Mode (Lamp Off): 3 W Standby Mode (Lamp Off): 0.5 W |
| Dimensions (W x H x D) | 8.5 x 6.2 x 13.9" / 21.6 x 15.7 x 35.3 cm Including feet 14.8 x 4.3 x 11.4" / 37.6 x 10.9 x 29.0 cm Excluding feet and lens |
| Weight lb | 15.2 |
| Package Weight | 23 lb |
| Box Dimensions (LxWxH) | 24.5 x 21.8 x 9.4" |
