Product Overview
Enjoy high contrast, long life, and low maintenance with the PT-REZ10L 10,000-Lumen WUXGA DLP Laser Projector in white from Panasonic. With 10,000 ISO lumens and Evolved Dynamic Contrast, the REZ10 series is ideal for medium sized venues, such as higher education and corporate conference centers, retail spaces, and museums.
This model does not ship with a lens, but has a selection of compatible lenses to cover different size and distance uses that are easier to set up than previous generations. The new suite of Panasonic lenses feature Lens Memory and Auto Lens Identification functions and now offer powered periphery focus adjustment operable via remote control or the Smart Projector Control app. Input connectivity is available via HDMI, DisplayPort, and an Intel SDM compatible upgradeable slot. The REZ10 series comes equipped with a full suite of professional features and software ready to simplify the trickiest installations.
Specifications
Key Specs
Display System 1-Chip 0.80" DLP
Native Resolution 1920 x 1200
Maximum Brightness 10,000 Lumens (ISO)
HDR Support Yes,
Inputs/Outputs
2x HDMI Audio, Video Input
1x DisplayPort Audio, Video Input
1x BNC Control, Data Input
1x BNC Control, Data Output
1x DE-9/DB-9 (RS-232) Control Input
1x DE-9/DB-9 (RS-232) Control Output
1x 1/8" / 3.5 mm Mini Remote Input
1x 1/8" / 3.5 mm Mini Remote Output
1x DE-9/DB-9 Remote Input
1x RJ45 (Ethernet) Control, Data, LAN Input
1x USB-A Control, Data, LAN Input
Light Source Laser Phosphor
Image Display
Display System 1-Chip 0.80" DLP
Native Resolution 1920 x 1200
Supported Resolutions Maximum: 3840 x 2160 @ 60 Hz
Maximum Brightness 10,000 Lumens (ISO)
Aspect Ratio Native: 16:10
Dynamic Contrast Ratio 25,000:1
Lens
Includes Lens No
Features
Keystone Correction
Vertical: ± 40°
Horizontal: ± 40°
HDR Support Yes,
Multi-Input Support (PIP/PBP) Not Specified by Manufacturer
Ceiling Mountable Yes
Rear Screen Projection Yes
Built-In Speaker No
Projection Tilt Option Yes
Input/Output Connectors
Inputs/Outputs
2x HDMI Audio, Video Input
1x DisplayPort Audio, Video Input
1x BNC Control, Data Input
1x BNC Control, Data Output
1x DE-9/DB-9 (RS-232) Control Input
1x DE-9/DB-9 (RS-232) Control Output
1x 1/8" / 3.5 mm Mini Remote Input
1x 1/8" / 3.5 mm Mini Remote Output
1x DE-9/DB-9 Remote Input
1x RJ45 (Ethernet) Control, Data, LAN Input
1x USB-A Control, Data, LAN Input
HDCP Support Yes, Version 2.3
Media/Memory Card Slot No
Number of Expansion Slots 1
Hardware
Mobile App Compatible Yes: Android & iOS
Wireless LAN / Wi-Fi No, Optional Adapter Available
Bluetooth No
General
Light Source Laser Phosphor
Expected Lamp Life
Full Brightness: 20,000 Hours
Low Brightness: 24,000 Hours
Fan Noise Medium Brightness: 36 dB
Security
Cable Lock Slot
Password Protection
Security Bar
Supported Languages
English
French
German
Italian
Japanese
Korean
Portuguese
Russian
Simplified Chinese
Spanish
Traditional Chinese
Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption
Full Brightness: < 840 W
Low Brightness: 540 W
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 10 to 80%
Dimensions (W x H x D) 19.6 x 8.3 x 21.2" / 498.0 x 212.0 x 538.0 mm (With feet at shortest position)
Weight 59.5 lb / 27 kg
Packaging Info
Package Weight 75 lb
Box Dimensions (LxWxH) 32 x 25.5 x 15"
