Samsung QH75B 75" 3840x2160 4K UHD Display 700 nit 8ms 24/7

Samsung QHB Series combines enhanced professional features, streamlined setup and maintenance and stunning design to elevate any business environment. From improving collaboration to showcasing rich content in new formats, QHB delivers innovation and efficiency to help businesses reach their goals.

All QHB Series displays feature reliable, non-glare panels that provide better visibility from all angles, any time of day. The non-glare display enables businesses to deliver accurate information in critical locations, such as airports and train stations.

The QHB series blends perfectly into any business environment. With the clean cable guide feature, the screen draws maximum focus to what is on the display, not the cables connected to it. Connect with colleagues without unnecessary connections.

Featuring easier video conferencing than ever, the QHB has a built-in video conference solution that supports the most popular web conferencing apps, enabling simple video calls with just a USB-type webcam. Upload any piece of content, no matter how innovative.

QHB's constant web-engine upgrades enable the latest types of content to be played without limitations, allowing for more diversified and engaging creative assets.

Specifications:

Panel

• Diagonal Size75"
• TypeVA
• Resolution3840x2160(16:9)
• Pixel Pitch(mm)0.42975 x 0.42975
• Active Display Area(mm)1650.24 (H) x 928.26 (V)
• Brightness(Typ.)700 nit
• Contrast Ratio6000:1
• Viewing Angle(H/V)N/A
• Color Gamut92% (DCI-P3, CIE 1976)
• Operation Hour24/7
• HazeNon-Glare

Sound

• Speaker Type10W 2ch

Connectivity

Input

• VideoDP 1.2 (1), HDMI 2.0 (3)
• HDCPHDCP2.2
• USBUSB 2.0 x 2

Output

• AudioStereo mini Jack

• External ControlRS232C(in/out), RJ45
• BT/WiFiYes

Power

• Power SupplyAC 100 - 240 V, 50/60 Hz

Power Consumption

• Max[W/h]264.0
• Typical[W/h]195.0
• Sleep modeless than 0.5W

Mechanical Specification

Dimension (mm)

• Set1681.1 x 960.1 x 49.7
• Package1871 x 1127 x 223

Weight (kg)

• Set40.3
• Package51.0

• VESA Mount (mm)400 X 400
• Bezel Width (mm)11.5mm(U/L/R), 12.5mm(B)

Operation

• Operating Temperature 0    ~   40
• Humidity 10.0  %  ~   80.0   %

Feature

• Key FeaturesUHD Signage with Built-in MagicInfo S10, SSSP 10.0
• OrientationLandscape / Portrait
• Remote ControlN/A

• Special Features H/W : Symmetric Design (same with QxR) Center IR Temperature Sensor Auto Level Wi-Fi(2.4/5.0GHz dual) & BT S/W : Workspace (Microsoft365/VMWare/RDP) Custom Home Auto Source Switching & Recovery Dicom Simulation Mode Director Mode SmartView+(PC) [end of march~] Upgradable Web-Engine Tizen Enterprise Platform Smart Calibration SmartView+(mobile) Video Conference Solution

Internal Player

• ProcessorCortex A72 1.7GHz Quad-Core CPU
• On-Chip Cache MemoryN/A
• Clock SpeedN/A
• Main Memory InterfaceN/A

• GraphicsN/A
• Storage (FDM)16 GB
• MultimediaN/A
• IO PortsN/A

• Operating SystemTizen 6.5

Certification

• Safety60950-1 / 62368-1
• EMCClass B
• Security802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP

Accessory

• IncludedQuick Setup Guide, Warranty Card, Power Cord RS232C(IN) Gender Remote Controller & Batteries

Optional

• StandNo
• Mount WMN4277SF (Land Only)WMN6575SF
• SpecialtyCLM450T
