JBL Bar 700 620W 5.1-Channel Dolby Atmos Soundbar System

DOLBY ATMOS® SURROUND SOUND

Immerse yourself in theater-quality 3D sound. With detachable surround speakers and Dolby Atmos® technology, the JBL Bar 700 delivers a 3D cinematic experience.

REAL SURROUND SOUND WITH DETACHABLE SURROUND SPEAKERS

Enjoy real surround sound without the hassle of extra wires and power connections. Just place the two detachable battery-powered surround speakers behind you and get swept away in amazing audio.

BUILT-IN WI-FI WITH AIRPLAY, ALEXA MULTI-ROOM MUSIC AND CHROMECAST BUILT-IN™

Get ready to explore. Access over 300 online music streaming services through AirPlay, Alexa MRM and Chromecast built-in™. Enjoy all of your favorite audio content, Internet radio, and podcasts in high definition. The Wi-Fi connection also allows automatic software updates, so you can always enjoy the latest features.

Specifications

General Specifications
Sound system 5.1 channel
Power supply 100 - 240V AC, ~ 50/60Hz
Networked standby power < 2.0W
Operating temperature 0°C - 45°C

Audio Specifications
Total speaker power output (Max @THD 1%) 620W
Soundbar output power (Max @THD 1%) 240W
Surround speaker output power (Max @THD 1%) 2x 40W
Subwoofer output power (Max. @THD 1%) 300 W
Soundbar transducer 3x (46x90)mm racetrack drivers, 3x 0.75" (20mm) tweeters
Surround speaker transducer 1x (46x90)mm racetrack driver
Subwoofer transducer 10” (260mm)
Frequency response 35Hz - 20kHz (-6dB)
Audio inputs 1 Optical, Bluetooth, Chromecast Built-in, AirPlay and Alexa MRM, USB (USB playback is available in US version. For other versions, USB is for Service only.)

Dimensions
Total soundbar dimensions (W x H x D) 1174 x 56 x 120 mm / 46.2" x 2.2" x 4.7"
Main soundbar dimensions (W x H x D) 884 x 56 x 120 mm / 34.8" x 2.2" x 4.7"
Detachable surround speaker dimensions (each) (W x H x D) 145 x 56 x 120 mm / 5.7" x 2.2" x 4.7"
Subwoofer dimensions (W x H x D) 305 x 440.4 x 305 mm / 12" x 17.3" x 12"
Soundbar weight 3.2 kg / 7.04 lbs
Detachable surround speaker weight (each) 0.65 kg / 1.4 lbs
Subwoofer weight 10 kg / 22 lbs
Packaging dimensions (W x H x D) 1000 x 375 x 475 mm/ 39.4" x 14.8" x 18.7"
Packaging Weight 18.7 kg / 41.1 lbs

Control and Connection Specifications
USB port Type A
USB rating 5V DC, 0.5A
Supporting file format MP3
MP3 codec MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate 16 - 48 kHz
MP3 bitrate 80 - 320 kpbs
Bluetooth version 5.0
Bluetooth profile A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range 2400MHz – 2483.5MHz
Bluetooth transmitter power <15dBm (EIRP)
Wi-Fi network IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range 2412 - 2462 MHz (2.4GHz ISM Band, USA 11 Channels)
2.4G Wi-Fi transmitter power < 20dBm (EIRP)
5G Wi-Fi transmitter frequency range 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz
5G Wi-Fi transmitter power 5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)
2.4G wireless transmitter frequency range 2406 - 2474MHz
2.4G wireless transmitter power ＜10dBm (EIRP）

Battery
Lithium battery 3.635V, 3283mAh
Detachable surround speaker playtime up to 10 Hours (may vary according to content type and volume level)

Video Specifications
HDMI video input 1
HDMI video output (with Enhanced Audio Return Channel, eARC) 1
HDMI HDCP version 2.3
HDR pass through HDR10, Dolby Vision

What's in The Box?
1x Main soundbar
2x Detachable wireless surround speakers
1x Wireless subwoofer
Remote control with 2 x batteries
2x Power cords
1 x HDMI cable
2 x L-shape wall-mount bracket (main bar) + 2 x U-shape wall-mount bracket (for surround speakers) kit with screws
4 x Side caps
Quick start guide
Safety instruction and Warranty card
Wall mount template
