Product Overview
Samsung QM43R-T 43" 4K UHD Commercial Smart Touchscreen LED Display
Engage potential clients and customers with the Samsung QMR-T 43" 4K UHD Commercial Smart Touchscreen LED Display. It is designed to support a variety of content types with touchscreen interactivity to suit your business needs. It features DisplayPort, DVI-D, and two HDMI inputs to display your digital HD content, plus two USB ports for multimedia playback. The QMR-T also has two built-in speakers for presenting visual content with audio.
Key Features
- 4K UHD (3840 x 2160) Native Resolution
- 8 ms Response Time
- Capacitive Touchscreen Technology
- Built-In Wi-Fi Connectivity
- DVI-D, DisplayPort 1.2, 2 x HDMI 2.0 In
- HDMI Output for Loop-Through
- Tizen 4.0 Operating System
- Dual Built-In 10W Speakers
- IP5X Rating
- Digital Signage Capable
All-in-One Interactive Digital Signage Solution
The QMR-T combines an embedded media player with MagicINFO—Samsung's leading-edge digital signage CMS platform—with the powerful Tizen OS, multi-touch interactivity, and a 4K UHD display into an all-in-one solution. Eliminate the need for an external player and enable a wide variety of apps.
Multi-Point Capacitive Touch
A responsive capacitive touch functionality makes for an engaging and intuitive experience.
Bright 4K UHD, Non-Glare Panel for Sharp, Captivating Messages
4K UHD resolution delivers incredibly clear and detailed content. Non-glare glass fitted onto the display helps to improve visibility and remove any distracting reflections, even in bright ambient light. And the haze coating on the glass creates a smooth touch.
IP5X for Lasting Durability
Samsung's QMR-T series display has received the IP5X rating standard, helping to ensure efficient and reliable performance, even in dusty environments, to protect the display from repeated customer interactions. In addition, a conformal coating on the display provides longevity even in public spaces, and as a result, helps to save on the overall cost of operation.
Convenient Control with a Centralized IR Receiver
Control your content easily with an intelligently designed IR receiver. Instead of a single point of reception, QMR-T series displays receive IR signals across their entire panels, making remote content control much easier and more reliable.
A Complete Digital Signage CMS Platform to Power Your Business
MagicINFO, Samsung's digital signage CMS platform, makes content management easier, more flexible, and more robust. Easily create content with the included templates. Use data capture tools to inform content creation and automated, targeted distribution. Manage it all from a single source.
Reliable 24/7 Continuous Operation
Commercial-level cooling technologies offer dependable reliability with a 24/7 continuous runtime.
Samsung QM43R Specs
Display
| Screen Size (Diagonal) | 43" |
| Resolution | 3840 x 2160 |
| Panel Type | LCD |
| Brightness | 400 cd/m² (Typical) |
| Viewing Angle (H x V) | 178 x 178° |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 5000:1 |
| Response Time | 8 ms |
| Backlighting Technology | Edge LED |
Connectivity
| Primary Connectivity Location | Display |
| Input Ports | 2 x HDMI 2.0 Audio, Video 1 x DisplayPort 1.2 Audio, Video 1 x DVI-D Video 1 x 1/8" / 3.5 mm Audio |
| Output Ports | 1 x HDMI 2.0 – Audio, Video 1 x 1/8" / 3.5 mm – Audio |
| USB Ports | 2 x USB 2.0 Type-A |
| Control | RS-232C via 1/8" / 3.5 mm Input/Output RJ45 |
| Wi-Fi | Built-in |
| Bluetooth | Yes |
General
| HDCP Support | Yes, Version 2.2 |
Surface
| Touchscreen Technology | Capacitive |
Audio
| Built-In Speakers | Yes, 2 x 10 W |
| Speaker Configuration | 2-Channel |
Hardware
| Operating System | Tizen 4.0 |
| CPU | 1.7 GHz Cortex A72 Quad-Core |
| Storage | 8 GB |
| RAM | 2.5 GB LPDDR4 1500 MHz |
Convenience
| Supported Video File Types | H.263, H.264/AVC, MPEG2, MPEG4, VC-1, VP8, VP9 |
| Supported Audio File Types | AC3 |
| Supported Photo File Types | JPEG, PNG |
Electrical
| Power Consumption | Typical: 72.0 W Maximum: 110.0 W Standby: 0.5 W |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 10 to 80% |
| Certifications | ENERGY STAR, as per Manufacturer |
Physical
| Wall Mounting | 200 x 200 mm |
| IP Rating | IP5X |
| Bezel Thickness | 26 mm (Bottom/Top) 21 mm (Right/Left) |
| Duty Cycle | 24 Hours / 7 Days |
| Dimensions | 38.8 x 23.0 x 2.2" / 986.2 x 584.4 x 56.7 mm |
| Weight | 32.0 lb / 14.5 kg |
Packaging Info
| Package Weight | 40 lb |
| Box Dimensions (LxWxH) | 44.25 x 28 x 5.5" |
Warranty Information
1 Year Parts & Labor Manufacture Warranty
